Regulator Inline Adjustment Tool

Description

About Regulator Inline Adjustment Tool – by XS ScubaSKU: TL121

• Adjust the low pressure orifice while the second stage is pressurized

• Two drives allowing compatibility with nearly all second stages

• Reversible, one end with with a 0.32 in (8.2 mm) slotted drive and the other with a tapered 5 mm hex drive

• Low pressure gauge included for display of the intermediate pressure

• Finger tight spin-on attachment for quick service

Components:

Low Pressure Gauge(p/n GB02)

• Dual scale gauge 0 to 300 psi and 0 to 20 bar

• 2.75 in (69.8 mm) diameter

• Stainless steel case

• Above water use only

Gauge Boot(p/n GP17)

• Included with fill checker

• Snug fitting, silicone compound for protection of gauge

Reversible Low Pressure Gauge

• Swap the gauge from left to right side to allow access to both drives

• Hand tighten fittings, no wrench needed

• One side: 0.32 in (8.2 mm) slotted drive

• Other side: 5 mm hex drive
